250VO-91L Vacuum Drying Oven

250C 91L Vacuum Drying Oven series vacuum drying oven is CE certified. A 50-500ml flow meter is installed in the front panel for user to simply control and create a gas environment in the chamber.

The oven adopts heat radiant wall system providing optimal uniformity and conserves chamber space for drying, curing, vacuum embedding, and plating applications.

Standard Parts:

Operation:

1) For using under vacuum, it is necessary to have the vacuum pump

2) 30 segments temperature profile programmable

3) Vacuum level displayed on gauges from 0 to 30" Hg

4) PID precision Digital Power controller controls temperature with a uniformity of +/-5C@ 100C; 25" Hg at center hot zone, 6'x6' center area only) and built-in over temperature protection
