VN-1200C Crucible Furnace

No price
Cumulative sales0Cumulative evaluation0
MOQ
1pcs
Payment
T/T, Western Union, Paypal, L/C
Shipment
By Sea; By Air; By DHL/Fedex
Packaging
In Standard Exporting Package
Quantity
- +
Collect
Description

1200C Crucible Furnace possesses the advantages of fast heating (20-40mins) , energy saving, high accuracy of controlling the temperature, reliable heat keeping, auto heating and cooling by programming and a furnace temperature nearing to the indoor. It is widely used in the laboratory and manufacture of the field of pottery, chemical industry, metallurgy, and glass industries, new material developing, machinery, fire-proof material, architecture, special material and etc.



Furnace:

1. Controlling Accuracy: +/-1C

2. Temperature uniformity: +/-1C (according to the heating chamber size)

3. Control system: Micro-computer controlled, Easy to operate, programmable, automatic heating up, automatic heat preservation, automatic cooling.

4. Working temperature: 1100-1200C

5. Stainless steel Metallic flanges sealing (Double rubber ring)

6. Outside temperature of the furnace is close to room temperature

7. Double-circuit protection

8. Super refractory material, Excellent thermally resistant, High temperature resistant, Thermal shock resistant


Technical Data


Chamber Size

Dia240 x Height 220mm

Power

2.2 KW

Voltage

AC 110V or AC 220V 50/60 Hz

(please tell us when your place order.)

Max. Temperature

1200C  (< 3 hours)

Continuous work temp.

1100C

Max. Heating Rate

30C /min

Temperature controller

• PID automatic control and auto-tune function.
• 51 programmable segments for precise control.
• Built in protection for over-heated and broken Thermal couple.
• Larger digital control panel (96 x 96 mm) for easy operation.

Temperature Accuracy

+/- 1C

Heating Element

Spring wires of Fe-Cr-Al Alloy doped by Mo

Thermal Couple

K type

Outer Dimension

510 x 435 x 425mm

Gross weight

with package

80 Kgs

Accessories

 (free charge)

1 pair of glove

1 crucible tong

Warranty

2 year limited warranty

(Consumable parts such as thermocouple and heating elements are not covered by the warranty)

Certificate

CE certified, ISO9001:2008
