VN-1700BL Bottom Loading Furnace

: ~~No price~~

Cumulative sales0

Cumulative evaluation0

MOQ: 1pcs

Payment: T/T, Western Union, Paypal, L/C

Shipment: By Sea; By Air; By DHL/Fedex

Packaging: In Standard Exporting Package

Quantity: - +

Proceed to Check Out Add to Cart

Collect

Description

1700C Bottom Loading Furnace possesses the advantages of fast heating (20-40mins) , energy saving, high accuracy of controlling the temperature, reliable heat keeping, auto heating and cooling by programming and a furnace temperature nearing to the indoor.

It is widely used in the laboratory and manufacture of the field of pottery, chemical industry, metallurgy, and glass industries, new material developing, machinery, fire-proof material, architecture, special material and etc.

Application:

Bottom Loading Furnaces are widely used in the fields of metallurgy, ceramics, glass, machinery, analysis test, semiconductor, science & research and so on.

Technical Data


Chamber Size	200x200x200mm
Power	6.5KW
Voltage	AC 110V or AC 220V 50/60 Hz (please tell us when your place order)
Max. Temperature	1700 °C (< 3 hour)
Continuous work temp.	1600 °C
Max. Heating Rate	15 °C /min
Temperature controller	• PID automatic control and auto-tune function • 51 programmable segments for precise control • Built in protection for over-heated and broken Thermal couple • Larger digital control panel (48 x 96 mm) for easy operation.
Temperature Accuracy	+/- 1 °C
Heating Element	Super MoSi2 heating element
Thermal Couple	B type
Outer Dimension	550X580X1650mm
Gross weight with package	250kgs
Accessories (free charge)	1 pair of glove 1crucible tong 2pcs MoSi2 heating elements
Software to control furnace through computer	• Communication module installed in temperature controller • software –TCS(Temperature Control System, available for Win2003, Win XP) • One USB cable, one RS485 Serial interface. (if you need, additional order)
Warranty	2 years limited warranty (Consumable parts such as thermocouple, o-rings and heating elements are not covered by the warranty)
Certificate	CE certified
