VN-1200BL Bottom Loading Furnace

1200C Bottom Loading Furnace: The single zone, high temperature, bottom loading furnace is capable of operating at temperatures up to 1200.C in air.

The furnace utilizes Fe/Cr/Al Alloy resistance wire positioned on three sides of the internal chamber. The furnace utilizes an energy efficient insulation package consisting of graded ceramic-fiber, high temperature insulation. It is an ideal tool for materials annealing and sintering.

Features:

1. Controlling Accuracy: +/-1C

2. Temperature uniformity: +/-1C (according to the heating chamber size)

3. Control system: Micro-computer controlled, Easy to operate, programmable, automatic heating up, automatic heat preservation, automatic cooling.

4. Working temperature: 1100C

5. Stainless steel Metallic flanges sealing (Double rubber ring)

6. Outside temperature of the furnace is close to room temperature

7. Double-circuit protection

8. Super refractory material, Excellent thermally resistant, High temperature resistant, Thermal shock resistant

Application:

Bottom Loading Furnaces are widely used in the fields of metallurgy, ceramics, glass, machinery, analysis test, semiconductor, science & research and so on.

1. Gravimetric Analysis;

2. Sintering or Roasting or Forging or Calcining;

3. Quantitative Analysis;

4. Heat Treating or Preheating;

5. Quenching or Hardening or Austempering

6. Annealing or Tempering or Normalizing

7. Stress Relieving

8. Temperature Measurement
